Model	Unit	APH-60	APH-80	APH-125	APH-150	APH-200	APH-220	APH-300	APH-350	APH-400	APH-550
Capacity	Ton	60	80	125	150	200	220	300	350	400	550
Stoke	mm	30	30	30	30	30	30	30	30	30-50	40
Stoke Per Minute	s.p.m	200-800	200-700	150-700	150-700	150-600	150-600	150-400	150-400	150-350	80-250
Bolster Area	mm	950×650	1100×750	1200×850	1400×850	1800×950	1900×1000	2200×1000	2400×1000	2800×1200	3300×1300
Bolster Hole	mm	700×125	800×150	1000×200	1000×200	1300×250	1400×300	2000×300	2200×300	2200×400	3300×500
Slide	mm	950×420	1100×500	1200×600	1400×600	1800×700	1900×750	2200×900	2400×900	2800×1100	3300×1200
Die Height Adjustment	mm	300-350	330-380	360-410	360-410	370-420	370-420	400×450	400-450	420×480	500-550
Adjusting Moter	kw	0.4	0.75	0.75	0.75	1.5	1.5	2.2	2.2	3.7	5.2
Linear Height	mm	160	175±50	195±50	195±50	200±50	200±50	210±50	210±50	220±50	240±50
Main Motor	kw	10	22	37	.37	45	12	55	55	75	90

RPH-200 SERIES

Gant Type Speed Precision Four Post Guide Press Machine
