RPD Series Ring Frame Type High Precision Press
RPD Series Ring Frame Type High Precision Press, Best Power Presses
Technical Specifications
|
Name
|
Unit
|
RPD-80
|
RPD-110
|
RPD-160
|
RPD-200
|
RPD-260
|
| Model |
Ton
|
V H
|
V H
|
V H
|
V H
|
V H
|
| Capacity |
mm
|
80
|
110
|
160
|
200
|
260
|
| Rated tonnage point |
mm
|
4 2
|
6 3
|
6 3
|
6 3
|
7 3.5
|
| Stoke |
mm
|
150 70
|
180 80
|
200 90
|
200 100
|
250 150
|
| Die Height |
s.p.m
|
340 380
|
360 410
|
460 510
|
460 510
|
500 550
|
| Stoke per minute |
mm
|
35-80 80-120
|
30-60 60-90
|
20-50 40-70
|
20-50 50-70
|
20-50 50-70
|
| Slide Adjustment |
mm
|
80
|
80
|
100
|
110
|
120
|
| Slide Area |
mm
|
560x420x70
|
650x470x80
|
700x550x90
|
850x630x90
|
950x700x100
|
| Bolster Area |
kw.p
|
760x550x90
|
900x600x110
|
980x880x140
|
1140x820x160
|
1500x840x180
|
| Main Motor |
HP
|
7.5
|
11
|
15
|
18
|
22
|
| Slide Adjust device |
kg/cm2
|
ELECTRICAL DRIVING
|
||||
| Air Pressure |
mm
|
6
|
6
|
6
|
6
|
6
|
| Presses Dimension |
ton
|
1300x1890x3000
|
140x1985x3200
|
1600x2200x3500
|
1750x2500x3900
|
2780x1850x4470
|
| Presses Weight |
7.8
|
10.5
|
17.8
|
25.3
|
32
|
|
| Presses Precision |
ton
|
GB(JIS) 1CLASS
|
||||
| Die Cushion Capacity |
mm
|
3.6
|
6.3
|
10
|
14
|
14
|
| Stroke |
mm2
|
70
|
80
|
80
|
100
|
100
|
| Die Cushion Effective Area |
450×310
|
500×350
|
650×420
|
710×480
|
810×480
|
Characteristic
All Specifications, dimensions and design characteristics shown in this catalogue are subject to change without prior notice.
